Connect Way |
Wire to Strip, Strip to Strip |
|
Application |
Single color,CCT, RGB,RGBW LED Strip |
|
PCB Width |
8MM,10MM,12MM |
|
Waterproof Rating |
IP20 Non-waterproof, IP65 Glue coating |
|
Working Voltage |
0-36V |
|
Working Current |
5A |
|
PCB Thickness |
0.2mm～0.4mm |
|
Workable Wire Gauge |
22~18 AWG |
|
Suitable Wire size |
0.35 mm²～0.75 mm² |
|
Workable Wire OD |
Φ1.5 mm～Φ 2.1mm |
|
Housing Material |
PC |
|
Pin Material |
Phosphor Copper (Cu) |
|
Connection with LED Strip |
Insulation-piercing connection |
|
Flame Retardant Level |
UL94v-0 |
|
Working Temperature |
-20 ℃～40 ℃ |
